Snow particle size and wind can change roof snow loads

When snow starts falling in a winter storm, many people assume the threat to buildings comes down to how many centimetres accumulate. Engineers do monitor those totals closely, because a deep snowpack can add huge weight to rooftops.

New research, however, indicates that the size of individual snow particles helps decide how much snow actually remains on a roof.

Bigger particles are more difficult for the wind to remove once they have landed, so they can stack up into deeper layers. Smaller particles, in contrast, are easier to lift and disperse.

Because of this largely unseen difference, two storms that deliver similar snowfall totals can leave very different roof loads behind.

Snow size shapes roof patterns

As wind flows over a roof, it tends to create irregular snow cover: some areas hold on to particles while other patches are scoured clean.

By analysing these patterns, Qingwen Zhang at Harbin Institute of Technology (HIT) showed that larger snow particles are less likely to be swept away after landing, allowing thicker deposits to persist.

Smaller particles, by comparison, are picked up and scattered more readily as the wind speeds up across the surface, resulting in shallower layers.

This uneven staying power means roof-snow depth is influenced not only by how much falls from the sky, but also by which particles remain in place long enough to build up.

After snow settles, the air moving across a roof can either press it down or pull it loose again. Larger grains carry greater momentum for their size, making it harder for gusts to lift or shove them away.

“In cold regions, snow load is a critical factor in structural design,” said Zhang. Engineers use the term snow load for that downward weight - the force snow exerts on a roof.

Wind and roof size change outcomes

Increasing wind strength does not remove every particle from a roof in the same way or at the same rate. As the airflow accelerates over the roof edge, fine particles tend to be lifted earlier, while bigger ones resist being drawn off.

At higher wind speeds this separation becomes more pronounced, meaning a storm may strip snow from one area even as another continues to thicken. When the snowfall stops, the final depth on the roof may reflect which particles endured as much as the total that fell.

Roof width also matters. On a broader roof, wind-blown snow has more distance over which it can settle and remain.

On narrower roofs, drifting snow is more likely to leave the surface sooner, whereas wider roofs keep more of it. One particle size was especially notable at about 0.5 mm (around 0.02 inches), where the added roof width corresponded with the deepest build-up.

Altogether, the result suggests roof form and scale can heighten snow hazards in ways that simpler approaches may not capture.

Modeling snow loads more realistically

Recreating an entire winter storm in a simulation can become prohibitively expensive if the model treats each snow particle size as a separate component.

To cut the computational burden, the researchers examined whether a single average particle size could stand in for the full mix.

Using that one value reproduced the behaviour of the complete range of sizes while requiring far less computing. For engineers, this offers a workable way to represent messy, wind-driven snow behaviour without resorting to extremely large simulations.

Getting the modelling right matters because building standards already classify snow as a major structural risk. If simulations smooth out particle differences, they may overlook locations where wind concentrates weight rather than distributing it evenly.

The US Federal Emergency Management Agency (FEMA) has warned that snow loads beyond design limits can leave buildings at risk of failure or collapse.

Findings like these could help building codes better match how storms truly deposit and strip snow across rooftops.

Roof shape and storms add complexity

Flat roofs made the clearest case for testing, but the central message is not limited to simple structures. Zhang noted that precise snow patterns would probably differ on pitched or arched roofs, even if the same particle-size rules still apply.

Ridges, curves and slopes redirect the airflow, changing where snow settles and where it is scoured away. That means the new results should be treated as a starting point rather than a complete solution, particularly for modern buildings with complex roof forms.

Real storms bring further complications. Temperature changes, melting, sticking, and shifts in snow-crystal shape can all affect what happens after snow lands.

To focus specifically on size, the team used tiny, sand-like silica particles in controlled laboratory experiments. This simplified arrangement enabled precise measurement, but removed some of the variability found in natural snowfall.

Researchers at HIT now intend to test curved and sloping roofs next, where airflow changes more abruptly.

Those studies should show whether the same modelling shortcut remains valid once roof geometry begins to exert a stronger influence on snow accumulation.

What this means for designers

For structural designers, a key takeaway may be that assuming snow is uniform is an unrealistically neat - and potentially risky - simplification.

“Accurately assessing snow loads for structural safety requires considering the natural variation in snowflake sizes, and ignoring this can lead to underestimation of snow accumulation in certain conditions,” said Zhang.

That shortfall could be most consequential on large roofs in windy locations, where snow distribution rarely stays even for long.

In practice, rooftop snow is as much about where it ends up as how much falls, shaped by particle size, wind, and the structure’s geometry.

Improved estimates will not remove winter hazards, but they can reduce blind spots before a storm hits.

As builders contend with harsher weather and increasingly varied architectural designs, small differences in how snow particles behave may determine whether safety margins hold steady or erode.

---
